宾得 Optio S4.pdf

■ SD logo is trademarked. and the QuickTime logo are trademarks used under license. The QuickTime logo is registered in the U.S. and other countries. ■ PENTAX and Optio are trademarks of PENTAX Corporation. ■ The USB driver uses software developed by inSilicon Corporation. Copyright © 2002 inSilicon Corporation. All rights reserved. ■ This product supports PRINT Image Matching II. When used in combination, PRINT Image Matching II enabled digital still cameras, printers and software help photographers to produce images more faithful to their intentions. Copyright 2001 Seiko Epson Corporation. All Rights Reserved. PRINT Image Matching is a trademark of Seiko Epson Corporation. The PRINT Image Matching logo is a trademark of Seiko Epson Corporation. ■ All other brands or product names are trademarks or registered trademarks of their respective companies. ■ QuickTime • Designs and specifications are subject to change without notice. • It is strongly recommended that you read the entire operation manual before operating this digital camera. • LCD images are simulated. • Some sample photos featured in this brochure were not taken using this product. • This brochure is printed on recycled paper. TM PENTAX U.S.A. Inc. 600 12th Street, Suite 300, Golden, Colorado, 80401, U.S.A. pentausa.com The Ultimate B lend of S ize and F unc tionality Thin and s tylis h, high quality, por table c ompac t zoom S T Y L IS H U S AB IL IT Y This high quality compact zoom camera lets you take images at an even higher level, while its ultra-portable dimens ions make it ready to us e, anytime, anywhere. The s tyling and des ign of the Optio S 4 is a res ult of many years of creating cameras at P E NTAX. The camera has a high sensitivity C C D and a s hutter with a rapid res pons e time, while remaining ultra s mall, ultra light, and thin. The camera features 4.0 effective megapixels and a 3X optical zoom, making it the pinnacle of compact digital cameras . The Optio S 4 us es the unique P E NTAX "S liding Lens s ys tem" to produce a s maller, thinner camera, that includes the ultimate in new technologies . The des ign is optimized for the us er through the natural pos itioning of buttons , with a us er-friendly four-way controller, that gives eas y control of the camera's myriad functions . P E NTAX’s long his tory of technical innovation has res ulted in the advanced technologies that combine to create the Optio S 4. The S liding Lens s ys tem with its amazing 3X optical zoom us es a unique technology that removes lens elements from the optical axis to reduce the s ize of the camera. A body with a new aes thetic - the ultimate in c ompac t s tyle. S pindle proces s on an aluminum alloy body, and a luxurious finis h. S tylis h, high grade des ign S witching On Three lens blocks combine along a single optical axis. L ens S tored T he c enter lens bloc k s lides up. S witc hing Off T he lens bloc ks are s tored in two s tages . that befits s uch a high-quality camera. High definition for great detail through the full maximum zoom range – 4.0 megapixels with a 3X optical, and 4X digital zoom The high-performance 3X optical zoom lens of the Optio S 4 produces beautiful pictures with minimal image dis tortion. Us e together with the 4X digital zoom, P OWE R FUL ZOOM to give a combined 12X zoom. 5.8mm equivalent to 35mm in (35mm ) format 17.4mm equivalent to 105mm in (35mm ) format 4X digital zoom equivalent to 420mm in (35mm ) format Image taken with O ptio S 4. A perture value : F 4. 8 S hutter s peed : 1/60 s ec . 3 4 E xplore the powerful and eas y-to-us e c apabilities of the Optio S 4 C O N VE N IE N T M O DE S Optio S 4 brings together a wealth of P E NTAX technology P rogram C ontrol a variety of functions to achieve the res ults you des ire. in a s ingle compact camera. In addition to P icture Mode, which lets you capture all the beautiful images you could des ire, it has a wide variety of functions to pleas e the novice through the advanced amateur. An eas y-to-operate P ic ture mode S elect a mode to match the s cene you want to take, and with a pres s of the s hutter, take expres s ive, beautiful, pictures quickly and eas ily. virtual mode dial gives you a wealth of modes , s o you can take the mos t appropriate s hot. L ands c ape E mphas izes rich hues , and the color contras t between greenery and sky. F lower P erfect for capturing the lus h colors and beauty of flowers . Autumn C olor C aptures the bright, rich colors of autumn. S elf-portrait Take s elf portraits , or add a friend to the frame. S uns et C aptures more lifelike colors , dis playing the warmth and beauty of the ris ing and s etting s un. P ortrait Faithfully reproduces natural s kin tones . S urf & S now Take pictures of water and s now s cenes , jus t as they appear. Night s c ene mode Night s cene mode is ideal for capturing images in the evening or at night. Us ing this mode together with the flas h lets you bring out detail in both your s ubject and in the background. Movie with s ound The Optio S 4 can record up to 60 s econds of video with s ound, at 15 frames per s econd, and 320 x 240 recorded pixels . The file is stored in AVI format, for easy playback on computers. *S ystem requirements: P C s running Windows 98/98S E , Me, 2000, or XP HomeE dition/P rofessional which came with DirectX 8.0 and Windows Media P layer installed, or have with QuickTime TM 6.0 or later installed (included on the accompanying C D-R OM), Macintosh machines running OS 8.6 or later with QuickTime 6.0 or later installed. 5 6 P anorama As s is t Take multiple pictures either vertically or horizontally as guided by the camera, and combine them us ing the provided computer s oftware to create breathtaking panoramas . *AC D photostitcher is compatible with Windows systems only. A range of us eful modes 3D image mode The 3D image mode gives you photos , which when viewed with the provided 3D image viewer, have a greater s ens e of depth and pers pective. E XT R A C APAB IL IT IE S E njoy taking pictures of a quality that belie the compact Digital F ilter proportions of this camera. Y ou can s elect black and white or s epia filters to create dramatic pictures , and the wide range of color filters (red, pink, yellow, green, blue, and purple) will als o let you influence the final photo. The Optio S 4 als o has a special slim filter, to make subjects appear narrower or broader than in real life. Mac ro s hooting mode Macro mode works at its optimum when the s ubject is as clos e as 7.1 inches (18cm), whereas S uper Macro mode has a fixed focus ing dis tance, s o you can get as clos e as 2.6 inches (6cm) to your s ubject. Us e with the maximum 4X digital zoom to make the s ubject even larger. This mode lets you have miniature s ubjects fill the whole frame, s o the camera can capture the s malles t details . S lim filter US E R The Optio S 4 offers a range of us eful s hooting modes , and it can als o memorize preferred combinations of s ettings . Infinity-lands c ape mode This mode s ets the focus to infinity, for cris p, clear focus when taking lands cape photos . Voic e rec ording mode The Optio S 4 can record up to 4 hours 22 minutes of s ound (with a 64MB memory component). E xplore the powerful and eas y-to-us e c apabilities of the Optio S 4 7 8 7-point autofoc us Tec hnology for pic tures jus t as you envis ion them U S AB IL IT Y The Optio S 4 offers a variety of convenient modes and features to s implify photography. Thes e features let you take even greater control of your photography. The 7-point autofocus s etting lets you capture your s ubjects eas ily, even when they are not in the center of the frame. When you're ready to s hoot, pres s the s hutter releas e button s lightly, and the autofocus frame will identify the area upon which the s hot will be focus ed. S pot AF S pot AF enables you to s elect a s pecific point for s harp focus from any of 49 locations within the frame, including in corners . Manual foc us L C D monitor The high-res olution, 1.6 inch LC D monitor helps you compos e pictures by showing the subject, and check images you have just captured. E as y playbac k R eviewing images you've captured is jus t as eas y as taking them. S imply pres s the playback button to view s tored photos . Us e the camera's s hutter releas e button to quickly switch back and forth from viewing to shooting modes. Nine-image dis play and Zoom dis play The manual focus function on the Optio S 4 allows you to adjus t the focus as you wis h. P rior to taking the picture, you can confirm your focus by viewing an enlarged image on the LC D s creen. White balanc e mode Us e white balance mode for adapting to the various natural lighting conditions you may encounter. In addition to an automatic s etting, there are daylight, s hade, and indoor lighting (tungs ten and fluores cent) options . There is als o a manual setting that gives you the freedom to experiment. E xpos ure c ompens ation E xpos ure compens ation from +2 to -2 E V in 1/3 s teps gives even broader expos ure control. The s creen can dis play up to nine images s imultaneous ly to make it eas ier to quickly s earch for pictures . The s creen can als o dis play images at up to 4X magnification, for checking focus and other details within pictures you have already taken. -1E V +1E V His togram dis play A graphical dis play on the LC D monitor s hows you more accurate information about lighting levels during both s hooting and playback, giving you more accurate control, and better pictures . Optic al Viewfinder Optio S 4 als o offers an optical viewfinder. This helps s ave power by reducing the need for the LC D monitor. B uilt-in auto flas h The flas h in the Optio S 4 can be s et to dis charge in low light conditions . The camera als o features Flas h on, Flas h off, and red-eye reduction* capabilities for increas ed vers atility. *This feature does not eliminate “red-eyes” in all instances. 9 Metering options Different s hooting s ituations call for different metering methods . With a choice of multi-s egment, center-weighted, and s pot metering options , the Optio S 4 gives you better pictures in almos t any s ituation. S ens itivity S ens itivity can be configured eas ily, either by s electing auto mode, or the IS O 50, IS O 100, or IS O 200 s ettings . 10 C amera c us tomization Y ou can cus tomize your Optio S 4 by choos ing a favorite image for your s tartup s creen, and by s electing operating s ounds . S elf-timer The Optio S 4 has a s elf-timer, s o you can take your own picture, or be in group s hots . R emote c ontrol Two optional remote control units are available. The zoomable remote control E and the remote control F allow three-s econd or immediate s hutter releas e. AV output terminal inc luded R ecorded pictures and audio can be enjoyed with eas e on your TV monitor! S imply us e the AV cable provided to connect the Optio S 4 to the televis ion. A full range of other us eful features DP OF func tion When us ed together with DP OF-compatible printers , the Optio S 4 lets you control the number of copies and the date dis play directly from the camera. *S ome printers may not support this function. P lease consult your printer manufacturer for more information. E xif P rint/P R INT Image Matc hing ll c ompatibility C O N VE N IE N C E S etting for s harpnes s , s aturation, and c ontras t AC DS ee for P E NTAX The Optio S 4 gives you the option of s etting s harpnes s , s aturation, and contras t in any of five s teps , for greater control over your picture taking, and for even more s atis fying res ults . AC DS ee for P E NTAX s oftware is eas y to ins tall on P C s and Macs . This makes it eas y to convert between graphic formats , create albums , manage your pictures , show thumbnails, and to view, edit, and print your pictures simply and quickly. World time func tion *S ystem requirements: P C s with P entium C P U or later, over 64MB memory capacity, over 40MB hard disk capacity, and a standard US B port. Macintosh machines with P owerP C 266MHz or later, over 8MB memory capacity, over 6MB hard disk capacity, and standard US B port. The world time function makes the Optio S 4 perfect for travel. It dis plays time information for 62 cities around the world, and can record the time photos were taken. Alarm c loc k func tion The perfect travel companion, the Optio S 4 can be us ed as an alarm clock, or to remind you of items on your s chedule. Mode memory func tion S ave combinations of picture taking settings using the mode memory function. The camera will automatically remember which mode was las t us ed, and return to that mode whenever you turn the camera on. Voic e memo func tion Make picture viewing even more fun, by adding up to 30 s econds of audio to your s till images . 11 When us ed together with E xif P rint and P R INT Image Matching ll compatible printers , the Optio S 4 can produce even more accurately printed colors . 11MB built-in memory The Optio S 4 has approximately 11MB of internal memory, that lets you capture images without any additional media. S D memory c ard / MultiMediaC ard(MMC ). US B mas s s torage c las s c ompatibility* The Optio S 4 works with the widely available S D memory cards and MultiMediaC ards, and for further convenience, data can be transferred easily between the built-in memory and these memory cards. US B connectivity lets you import data quickly and eas ily into a range of common s oftware applications, even allowing a number of images to be transferred simultaneously. *S ystem requirements: P C s running Windows 98/98S E , Me, 2000, or XP HomeE dition/P rofessional operating systems. Macintosh machines running OS 8.6 or later. 12 Nomenc lature S pec ific ations S elf-timer lamp Viewfinder R emote control receiver T ype C ompact-type digital s till camera with built-in zoom lens , autofocus , auto expos ure and auto flas h E ffec tive P ixels 4.0 megapixels S ens or 4.23 megapixels (total pixels ) 1/2.5 inch interline trans fer C C D with a primary color filter 10 bit 2304 x 1728 pixels , 1600 x 1200 pixels , 1024 x 768 pixels , 640 x 480 pixels 320 x 240 pixels Auto, fixed (equivalent to IS O 50, 100, 200) C olor Depth R ec orded P ixels B uilt-in flas h Lens S till M ovie S ens itivity F ile F ormats S till M ovie S ound Microphone Tripod s ocket Quality L evels S torage M edia S hutter releas e button Image S torage C apac ity P ower s witch Voic e R ec ording T ime M ovie R ec ording C apac ity / button Focus s tatus lamp (green) / Viewfinder Zoom / Flas h s tatus lamp (red) L ens s mc P E NTAX power zoom 5.8mm-17.4mm (equivalent to 35mm-105mm in 35mm format) F2.6-F4.8, 6 elements in 5 groups (2 dual-s ided as pherical elements ). Digital Z oom 1X - 4X button / button DC input terminal F oc us ing S ys tem T ype S trap lug LC D monitor F oc us ing Areas F oc us ing R ange Autofoc us S peaker P C /AV terminal Menu button B attery /C ard cover Dis play button Four-way controller ( ) (OK button in the center) / button P layback button M anual F oc us E xpos ure C ontrol M etering S ys tem E xpos ure M odes P ic ture M odes Digital F ilter E xpos ure C ompens ation M ovie S hutter S ys tem c hart Drive M odes F las h C ard R eader/Writer TV Monitor Video P rojecter AV C able (Acces s ory) SD Memory C ard P C C ard Adapter E ffec tive R ange PC P rinter W hite B alanc e S old S eparately 13 · R echargeable Lithium-ion B attery · B attery C harger · AC P lug C ord · 3D Image Viewer · AV C able · US B C able · S oftware (C D-R OM) · S trap · AC Adapter K it · R emote C ontrol E (with Zooming C apability) · R emote C ontrol F · S oft C as e TTL contras t detection autofocus s ys tem Manual focus /Infinity-lands cape mode available 7-point autofocus , s pot autofocus Normal: 1.31ft (0.4m) to infinity Macro: 0.59ft (0.18m) to 1.64ft (0.5m) S uper macro: 0.2ft (0.06m) to 0.65ft (0.2m) at 10.2mm (equivalent to 61.5mm in 35mm format) 0.2ft (0.06m) to infinity TTL metering: C hoice of Multi-s egment metering, C enter-weighted metering, S pot metering P rogram, P icture mode, Night s cene, Movie, P anorama as s is t, 3D image, Digital filter, Us er Landscape, Flower, P ortrait, S elf-portrait, S urf & S now, Autumn color, S unset B lack & White, S epia, R ed, P ink, P urple, B lue, G reen, Y ellow, S lim ±2 E V (1/3 s teps ) S hooting time: approx. 1 sec. - 60 sec.(depending on memory card capacity ) P rogra mmed AE electronic lens s hutter with C C D electronic s hutter. S hutter s peed: approx. 1/2000 s ec. to 4 s ec. One s hot, C ontinuous , R emote control, S elf-timer B uilt-in s eries -control auto flas h Automatic dis charge under low lighting conditions in auto modes . Flas h-on and Flas h-off modes . “R ed-eye” reduction function employs a pre-dis charge. Approx. 0.65ft - 11.5ft ( 0.2 m - 3.5 m) ( 5.8mm at S ens itivity 200 ) Approx. 0.65ft - 6.6ft ( 0.2 m - 2 m) ( 17.4mm at S ens itivity 200 ) Auto, Daylight, S hade, Tungs ten light, Fluores cent light, Manual s etting Actual-image zoom viewfinder 1.6 inch, TFT color LC D (Approx. 84,000 pixels ), field of view: Approx.100% Nine-image, 1X-4X magnification, s lide s how, voice memo available in playback mode. T ime Dis play the time in 62 cities (28 time zones ) Dis play an image with alarm (max. three memory s ettings ) Interfac es Video Output P ower S ourc es Dimens ions W eight Inc luded (G ood) 10 21 47 90 Optic al Viewfinder L C D M onitor L C D F unc tion US B C able (Acces s ory) Ac c es s ories J P E G (E xif 2.2), DC F, DP OF AVI (Motion J P E G format) 15 fps , with s ound WAV (ADP C M ), monaural (B es t), (B etter), (G ood) B uilt-in memory (approx. 11MB ), S D memory card, MultiMediaC ard (MMC ) E xpos ure capacity when us ing built-in memory. (B es t) (B etter) R ecorded P ixels 2304 x 1728 3 7 1600 x 1200 9 15 1024 x 768 19 36 640 x 480 43 67 46 min. (built-in memory) 59 s ec. x 1 files (built-in memory) W orld T ime Alarm C loc k AV output terminal, US B terminal, DC input terminal C ompatible with NTS C and P AL formats (monaural s ound ) R echargeable D-LI8 lithium-ion battery (allows approximately 180 s hots to be taken*). Optional AC adapter als o available. 3.3 x 2.0 x 0.8 inches (83(W ) x 52(H ) x 20(D) mm) (excluding protrus ions ) 4.1oz. (115g) loaded and ready 3.5oz. (98g) without battery and S D memory card * According to the results of in-house testing. (With LC D monitor on and flash used for 50% of the shots) 14
